Victron Orion 24/12-80 IP20 DC-DC Converter
$114.75
MSRP:
$135.00
Victron Orion 24/12-30 IP20 DC-DC Converter
- UPC:
- 8719076069591
- MPN:
- ORI241230022
- Condition:
- New
- Availability:
- In Stock
- Shipping:
- $5.95 Flat Rate (Per Order)
$76.50
MSRP:
$90.00
Fast shipping from Georgia
Ships within 1 business day
Trusted by 28,000+ customers
Established Since 2001
30-day hassle-free returns
Description
The Victron Orion 24/12-30 IP20 DC-DC Converter gives up to 30 amps of 12V output from a 24V system, with adjustable output and remote on/off.
Thirty amps is the smallest of the three IP20 Orion converters, below the 60A and 80A versions. Sizing to the actual 12V load rather than the largest available matters, since an oversized converter draws idle current continuously for capacity never used.
Thirty amps of output draws around 15 amps from the 24V side, and that figure sizes the supply cable and fuse. Planning from the output alone is the common error, and it leaves the input side undersized.
The remote on/off takes a low-power switch or an engine run/stop signal rather than the full input current. IP20 means a dry, protected mounting position, with the IP67 Orion range covering exposed and engine-space locations. Explore more DC-DC converters and power supplies.
- 30A, the smallest of three IP20 converters
- An oversized converter draws idle current for nothing
- 30A out draws around 15A from the 24V side
- IP20 needs a dry position, IP67 for an engine space
Specifications
- Amperage:
- 30A
- Product Type:
- DC-DC Converter
- Rating:
- IP20
- Google Feed:
- Yes
- Bing Feed:
- Yes
- Pinterest Feed:
- Yes
- Feed Brand:
- Victron
- Feed MPN:
- ORI241230022
- Feed GTIN:
- 8719076069591
Description
The Victron Orion 24/12-30 IP20 DC-DC Converter gives up to 30 amps of 12V output from a 24V system, with adjustable output and remote on/off.
Thirty amps is the smallest of the three IP20 Orion converters, below the 60A and 80A versions. Sizing to the actual 12V load rather than the largest available matters, since an oversized converter draws idle current continuously for capacity never used.
Thirty amps of output draws around 15 amps from the 24V side, and that figure sizes the supply cable and fuse. Planning from the output alone is the common error, and it leaves the input side undersized.
The remote on/off takes a low-power switch or an engine run/stop signal rather than the full input current. IP20 means a dry, protected mounting position, with the IP67 Orion range covering exposed and engine-space locations. Explore more DC-DC converters and power supplies.
- 30A, the smallest of three IP20 converters
- An oversized converter draws idle current for nothing
- 30A out draws around 15A from the 24V side
- IP20 needs a dry position, IP67 for an engine space
