Blue Sea 8043 AC Main +3 Position Toggle Panel

The Blue Sea Systems 8043 is a 120V AC panel with a 30A double-pole main plus 3 positions in white toggle format, measuring 7.5 by 5.25 inches.

Three branch circuits is a small boat's entire AC system, and this arrives with every position filled rather than as a shell. Three 7210 A-Series 15A toggles cover the branches and a 7238 double-pole 30A toggle serves as the main.

A 9353 voltmeter reading 0 to 150 volts sits on the face, so incoming shore voltage is visible before anything is switched on. That is unusual at this size. Most small AC panels leave metering out entirely and the owner never knows what the pedestal is actually delivering.

Four green 120V AC LEDs and one red are installed, the red being reverse polarity indication. Hot, neutral and safety ground buses are installed with the panel fully pre-wired, labels backlit as standard, and the 8031 basic AC label set with 30 labels included. Explore more marine electrical panels.

• Three branches, a small boat's whole AC system
• Every position filled from the factory
• Voltmeter on the face, unusual at this size
• Reverse polarity LED and pre-wired buses
