Veratron 200-600mm NMEA 2000 Liquid Level Sensor

The Veratron NMEA 2000 Liquid Level Sensor, 200-600mm, solves a long list of problems that plague older tank-level monitoring approaches, and it's the first of its kind certified for use in drinking water tanks specifically, not just fuel or waste.

Three model depths cover tank sizes from 200mm up to 1500mm, and a capacitive sensing element switches easily between fresh and waste water applications while micro-adjusting to match the specific tank's dimensions. Unlike older reed-switch technology, which only reports level in fixed graduated steps, this sensor's capacitive measurement gives linear readings across the entire tank depth, giving a boater precise, continuous data to make real decisions about refilling, pumping out, or discharging, across up to 4 tanks on one network.

Installation is plug-and-play: the sensor connects straight into the NMEA 2000 backbone through its integrated Micro-C M12 5-pin connector, drawing nominal 12V power directly from the network while making tank level visible on any compatible display already connected to that network.

The box holds a flange kit for mounting, a 300mm pigtail lead for the NMEA connection, a sealing kit, rubber gasket, bracket, and the hardware to install it. Sold individually.

There is more in our marine gauges.

• First liquid level sensor certified for drinking water use
• Capacitive sensing delivers linear readings across the full tank range
• Switches between fresh and waste water, micro-adjustable for tank size
• Supports monitoring across up to 4 tanks on one network
• UL94, CE, REACH, and RoHS compliant
• Rated IPX9K for fully exposed installation
