Trident Single Stage LPG Regulator w/Wall Mount

The Trident Single Stage LPG Regulator w/Wall Mount is a wall-mounted low-pressure marine LPG regulator assembly with an integrated 300 PSI pressure gauge. Its die-cast body and 3/8-inch female threaded outlet provide a compact way to regulate gas supply while moving the regulator to the locker wall instead of occupying space directly around the cylinder.

The assembly is UL Listed, 100 percent leak-tested, and identified by the source as meeting the ABYC Marine LPG Standard. The low-profile water-tight stainless-steel gauge supports leak testing, while the wall-mount arrangement leaves more room in the LPG locker for components such as a solenoid valve, manifold, or grill connection tee.

Connect the appropriate Trident pigtail hose from the cylinder to the regulator inlet and follow all applicable marine LPG installation requirements. LPG systems require correct locker ventilation, approved hose and fittings, shutoff arrangements, leak testing, and secure mounting. The listed regulator capacity is 100,000 BTU per hour.

• Moving the regulator to the locker wall preserves room around cylinders and other gas-system components.
• The 300 PSI low-profile gauge supports leak-test and pressure-check procedures.
• The regulator is UL Listed, 100 percent leak-tested, and identified as meeting the ABYC Marine LPG Standard.
• The listed capacity is 100,000 BTU per hour.
