Blue Sea 8025 DC 3 Position Breaker Panel

The Blue Sea Systems 8025 is a 3-position DC panel with white toggle switches, running 12 or 24 volts and rated to 100A.

At 3.75 inches tall by 5.25 wide it suits a small boat, or a second panel added to serve a specific area such as a cockpit or a cabin. That second-panel use is worth considering. Running three local circuits from a small panel near the equipment beats extending long branch runs back to a crowded main panel.

Three 7210 A-Series white toggle 15A breakers are installed, filling every position. Positive, negative and grounding buses are fitted and the panel arrives fully pre-wired, with backlit label positions and ON indicating LEDs throughout.

Metered versions read across up to three battery banks through a toggle switch, and analog meters can be upgraded to 24 volts later using the 8240 or 8243 units. The 8030 basic DC panel label set with 30 labels is included. Explore more marine electrical panels.

• Small enough for a boat or a second local panel
• Beats extending long runs to a crowded main panel
• Three 15A toggles installed and pre-wired
• 12 or 24 volts, rated to 100A
