Blue Sea 4306 WeatherDeck 6 Position Fuse Panel

The Blue Sea Systems 4306 is a WeatherDeck 6-position fuse panel in gray, rated IP67, with 15A per circuit and a 90A cumulative rating.

Bicolored LEDs behind the labels show red for off, green for on, and go dark when a fuse has blown, so a failed circuit identifies itself. A panel with no lights anywhere has lost power altogether, which distinguishes a dead panel from a blown fuse without touching anything.

Six positions is the smaller WeatherDeck fuse panel against the eight-position 4308, at 6.0 inches tall rather than 7.7. Protection is by ATO/ATC fuse rather than breaker, which seals better in an exposed position but means carrying spares aboard.

The front is rated IP67 with its watertight mounting gasket, good for immersion to one meter for 30 minutes, which open cockpit and flybridge mounting can involve. Label backlighting runs on an independent circuit for remote switching and dimming, four mounting orientations are available, and six switches, boots, fuses and the 4215 label kit are included. Explore more marine electrical panels.

• Bicolored LEDs: red off, green on, dark means blown
• No lights anywhere means the panel lost power
• Six positions against eight on the 4308
• IP67 to one meter for 30 minutes
