Marinco 1000 Series Wiper Motor - 2.5in, 110-Degree

The Marinco 1000 Series Wiper Motor - 2.5in, 110-Degree is a 12V heavy-duty marine windshield wiper motor with a 2.5-inch shaft and a 110-degree listed sweep configuration. The 1000 Series uses a fully sealed housing made from UV-stabilized, high-temperature, high-impact thermoplastic for exposed marine windshield installations.

The motor supports adjustable sweep settings of 50, 65, 80, or 110 degrees, plus adjustable right- or left-side self-parking. It is built to power compatible 18-inch Deluxe arm and blade combinations at sweeps of 80 degrees or less, or 16-inch Deluxe combinations at the 110-degree setting.

An anti-rotation drive shaft, knurled shaft, solid brass arm-drive nut, coast-to-park operation, and RF-shielded circuitry support reliable marine service. The retail version includes a 5-amp fuse and holder but not the operating switch. Confirm shaft length, sweep clearance, arm/blade size, wiring, and switch requirements before installation.

• Selectable 50, 65, 80, or 110 degree settings provide installation flexibility.
• Adjustable right- or left-side self-parking helps match the helm layout.
• The sealed UV-stabilized thermoplastic housing is designed for harsh marine environments.
• The motor supports specified 16- or 18-inch arm and blade combinations based on sweep angle.
• RF-shielded circuitry and an included 5-amp fuse and holder simplify system integration.
