EGIS MT 12-Position Sealed Ground Fuse Block

The EGIS MT 12-Position Sealed Ground Fuse Block is a compact branch-circuit distribution center with integrated Deutsch/Amphenol output connectors and a full ground-return bus. It supports up to 12 protected circuits while keeping the fuse block, output connections, and ground return organized in one sealed assembly.

Total output capacity is rated at 250A, and the integral ground-return bus is also rated at 250A. The enclosure is sealed to IP66 and IP6K9K for demanding marine and vehicle environments. Circuit protection can be provided with ATM/MINI fuses or Type 1 and Type 3 circuit breakers, allowing the installer to choose the protection device that fits each branch circuit.

EGIS covers the MT block with a 5-year manufacturer warranty. Fuses and circuit breakers are sold separately.

• 12 protected circuit positions with integrated sealed output connectors
• 250A total output-current capacity
• Integral 250A ground-return bus
• IP66 and IP6K9K sealed construction
• Accepts ATM/MINI fuses and Type 1 or Type 3 circuit breakers
