Black Oak 30 in Black Single Row Combo LED Light Bar

The Black Oak 30 in Black Single Row Combo LED Light Bar is a low-profile Pro Series 3.0 bar for trucks, UTVs, boats, and work vehicles that need strong forward lighting without the height of a double-row design. The housing stands about 1.8 in tall, which opens up mounting positions behind grilles, above roll cages, on headache racks, or along lower bumpers. Its combination optic mixes spot and flood coverage, giving the driver or boat operator both distance and broader peripheral light. That makes the bar useful when a single narrow beam would leave too much of the surrounding area dark.

Black Oak protects the bar with its 360-degree ceramic treatment for ultraviolet exposure, salt water, and corrosion. The two-stage Hydrex seal system supports full submersion, while the Dynamax housing is designed as a stronger frame for rough conditions. The Pro Series 3.0 platform also uses updated LED technology compared with earlier versions. A black exterior keeps the installation visually low key on dark bumpers, racks, and vehicle trim.

The bar is rated at 150W, draws 10.3A, and uses 30 LEDs. Black Oak lists 19,800 raw lumens, a weight of about 8.6 lb, and an IP69K ingress rating. Dimensions with the mounting bracket are approximately 33 in wide by 2.6 in high. The unit is backed by the company’s lifetime warranty.

Black Oak lists off-road driving, T-top boat lighting, UTV roof mounting, and truck bumper applications among the common uses. The package includes the 30 in bar, a complete wiring harness with fuse, relay, and switch, mounting brackets, and installation hardware. That complete electrical package is especially useful on a new installation where a dedicated relay and switch are not already present. Final beam aim should be set with both the spot reach and flood coverage in mind.

• Slim single-row housing approximately 1.8 in tall
• Combination spot/flood beam pattern
• Hydrex sealing for fully submersible construction
• Dynamax housing with ceramic corrosion protection
• Complete wiring harness, relay, switch, brackets, and hardware included

For more single-row and combination-beam LED light bars, browse more LED Light Bars & Pods.
